切片機適用于地質、冶金、建材、煤炭、石油等工業實驗室切取礦樣及其他材料如玻璃、陶瓷、玉石、石英、金屬試樣切片。本產品由原地礦部唯一指定企業生產行業標準。It serves to slice mineral sample in industrial laboratory of geology, metallurgy, building materials, coal and petroleum an
切片機適用于地質、冶金、建材、煤炭、石油等工業實驗室切取礦樣及其他材料如玻璃、陶瓷、玉石、石英、金屬試樣切片。本產品由原地礦部唯一指定企業生產行業標準。
It serves to slice mineral sample in industrial laboratory of geology, metallurgy, building materials, coal and petroleum and so on. It also serves to slice other materials, such as glass, ceramics, jade, quartz and metal
切片機技術參數 Core slicing machine
| 型號規格Model | 單位Uite | SPQJ-200臺式 | SPQJ-300 | SPQJ - 400 |
|---|---|---|---|---|
| 金剛石刀片尺寸 Diamond blade sinze | mm | Φ200 | Φ300 | Φ400 |
| 刀片線速度 Blade linear speed | m/s | 29 | 20-40 | 20 |
| 切割尺寸 Slicing dimension | mm | Φ15-Φ45 35×40 | ****60×70 | 100×100 |
| 功率 Power | kw/V | 0.55/380 | （0.8/1.1）/380 | 1.1/380 |
| 外形尺寸 Overall dimensions | mm | 720×515×415 | 825×800×1105 | 865×560×1010 |
| 質量 Weight | kg | 95 | 190 | 110 |
我們要求服務人員時刻關注客戶，及時解決設備問題，確保顧客的利益比一切都重要。
